Anti-Explosion Battery-Powered Trackless Transfer Cart for High Frequency and Curved Tracks

Name: AntiExplosion BatteryPowered Trackless Transfer Cart for High Frequency and Curved Tracks
Brand: BETTER
Price: 3000 USD

Buy cheap Anti-Explosion Battery-Powered Trackless Transfer Cart for High Frequency and Curved Tracks product

Model Number : BXC

Usage : Heavy Duty Material Transportation

Place of Origin : Xinxiang

Load Capacity : 1-300ton

Price : US$3000-3500

Packaging Details : Single Package: Dimensions 300×200×100 cm; Gross Weight 1000 kg; Quantity per Package 1 unit.

Material : Steel

Origin : Xinxiang

Supply Ability : 50 Sets/Month

Specification : 2000*2000*500

Table Size : 2000*2000*500

Running Speed : 0-25m/min

Wheel Diameter : 270-600mm

Payment Terms : L/C,T/T

Transport Package : The Whole Cart Will Be Packed by Tarp.

Wheel Base : 1200-7000mm

MOQ : 1 Piece

Special Function : Anti-Explosion,Heat-Resistant,Lifting,Customized

Delivery Time : 15-25 days

Trademark : BETTER

Production Capacity : 50 Sets/Month

Brand Name : BETTER

Product Name : Battery-Power Transfer Cart

HS Code : 84289090

Contact Now

Trackless Transfer Cart For High Frequency And Curved Tracks Anti Explosion

Product Overview

Our trackless transfer cart redefines efficiency and adaptability in complex industrial environments. Engineered to handle high-frequency operations and navigate curved or irregular routes with ease, it eliminates the limitations of traditional rail-bound systems.

The flexible steering mechanism and robust control system ensure smooth and precise movement even in congested or dynamically changing layouts. Enhanced with multi-layer safety features—including 360° obstacle detection, automatic speed regulation, and emergency braking—the cart guarantees reliable and secure transport of heavy or sensitive loads.

Ideal for assembly lines, processing zones, and warehouses with frequent layout adjustments, this solution boosts productivity, minimizes downtime, and supports seamless logistics in demanding settings.

Anti-Explosion Battery-Powered Trackless Transfer Cart for High Frequency and Curved Tracks

Product Images

Technical Specifications

Model	BXC-2t	BXC-5t	BXC-10t	BXC-16t	BXC-20t	BXC-25t	BXC-30t	BXC-40t	BXC-50t	BXC-63t	BXC-80t	BXC-100t	BXC-150t
Rated Load (t)	2	5	10	16	20	25	30	40	50	63	80	100	150
Table Size - Length (mm)	2000	3500	3600	4000	4000	4500	4500	5000	5500	5600	6000	6500	10000
Table Size - Width (mm)	1500	2000	2000	2000	2200	2200	2200	2500	2500	2500	2600	2800	3000
Table Size - Height (mm)	450	500	500	550	550	600	600	650	650	700	800	900	1200
Wheel Base (mm)	1200	2500	2600	2800	2800	3200	3200	3800	4200	4300	4700	4900	7000
Rail Inner Gauge (mm)	1200	1435	1435	1435	1435	1435	1435	1435	1435	1435	1800	2000	2000
Wheel Diameter (mm)	270	270	300	350	350	400	400	500	500	600	600	600	600
Wheel Quantity	4	4	4	4	4	4	4	4	4	4	4	4	8
Ground Clearance (mm)	50	50	50	50	50	50	50	50	50	75	75	75	75
Running Speed (m/min)	0-25	0-25	0-25	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-20	0-18
Total Power (kw)	2	3	2.2	2.2	2.2	3	3.5	4	5	6.3	8	10	15
Battery Capacity (Ah)	150	180	180	200	220	220	260	300	330	400	400	440	600
Battery Voltage (V)	48	48	48	48	48	48	48	48	48	48	72	72	72
Running Time When Full Load (hours)	4.32	5.4	4.8	4.3	4	4	3.5	3.6	3.3	3	3.6	3.2	2.9
Running Distance for One Charge (km)	6.5	8.1	7.2	5.1	4.8	4.8	4.2	4.3	4	3.6	4.3	3.8	3.2
Max Wheel Load (KN)	14.4	25.8	42.6	64.5	77.7	94.5	110.4	142.8	174	221.4	278.4	343.8	265.2
Recommended Rail Model	P15	P18	P18	P24	P24	P38	P38	P43	P43	P50	P50	QU100	QU100

Anti-Explosion Battery-Powered Trackless Transfer Cart for High Frequency and Curved Tracks

Customization Inquiry

How can Transfer Carts be customized?

Please provide the following information for customization:

What load or product will be transferred onto the cart?
What is the weight of the heaviest lift or load?
What are the dimensions? (Length; Width; Height)
What is the trip time and frequency? (# of Trips per shift, Shifts per day)
What is the travel area you need to cover? (Rail/cement floor, Indoor/Outdoor, straight line travel, etc)
What is the distance to travel?
Other relevant information or using conditions

Anti-Explosion Battery-Powered Trackless Transfer Cart for High Frequency and Curved Tracks

Key Advantages

Low Noise Operation

Produces minimal noise levels for improved working environment.

Maximum Safety

Comprehensive safety features ensure protection for operators and materials handled.

Easy Operation

User-friendly design with intuitive controls for immediate productivity.

Easy Integration

Operates on standard floors without complex or permanent installation requirements.

Versatile Capacity

Suitable for handling both small and extremely large loads with payloads up to 300 tons per trolley.

Anti-Explosion Battery-Powered Trackless Transfer Cart for High Frequency and Curved Tracks

Packaging & Shipping

Standard Container Shipping: For equipment with length less than 6m and width less than 2.2m, transported by 20ft container. For length between 5.9m and 12m, transported by 40ft container.

Multiple Units: 2-3 sets can be transported by full container. Single sets can be transported by LCL Container.

Oversized Equipment: For width beyond 2.2m with length less than 12m, transported by flat rack (20 or 40 ft). Equipment beyond these dimensions requires bulk cargo shipping.

Anti-Explosion Battery-Powered Trackless Transfer Cart for High Frequency and Curved Tracks

Certifications

Our products meet industry standards and certification requirements. Please contact us for specific certification details.
